F1T1 - Air filter upper housing
F1T1 - Air filter upper housing
SX5KCTQ15T65D05GR24C > engine > Engine assembly module > Engine assembly > Air filter upper housing
| Rep. | Designation | Reference | Qte/vehicule |
|---|---|---|---|
| 1 | Air inlet manifold assembly | F1T1-C0102-1010010 | 1 |
| 2 | Sealing ring | F1T1-C0102-1010020-6 | 1 |
| 3 | Hexagon flange bolt | F1T1-Q1860835F36 | 3 |
| 4 | All-metal hexagon flanged lock nut | F1T1-Q33008F36 | 2 |
| 5 | B-type worm drive hose hoop | F1T1-Q67670F36 | 1 |
| 6 | Intercooler air outlet pipe assembly | F1T1-C0102-1010030 | 1 |
| 7 | Hexagon socket head cap screw | F1T1-Q218B0655F36 | 4 |
| 8 | Flat washer | F1T1-Q401B06F36 | 4 |
| 9 | Sealing ring | F1T1-C0102-1010031 | 1 |
| 10 | throttle body | F1T1-C0101-1015471 | 1 |
| 11 | Sealing ring of throttle body | F1T1-C0102-1010012 | 1 |
| 12 | Double-ended stud | F1T1-Q1260835F36 | 2 |
| 13 | Cylinder head flange sealing ring | F1T1-C0102-1010011 | 2 |
| 14 | Intake air temperature and pressure sensor | F1T1-C0102-1016271 | 1 |
| 15 | Hexagon flange bolt | F1T1-Q1840616F36 | 1 |
| 16 | Intake manifold bracket | F1T1-C0102-1010071A | 1 |
| 17 | Hexagon flange bolt | F1T1-Q1840616F36 | 2 |
| 18 | Hexagon flange bolts-enlarged series | F1T1-Q1860625F38 | 1 |
| 19 | Hex head bolt and L-flat washer assembly | F1T1-Q140B0630F38L | 1 |
| 20 | Intercooled intake pipe assembly | F1T1-C0102-1010020 | 1 |
| 21 | Hexagon flange bolt | F1T1-Q1840825F36 | 3 |
Prezzo di listino
CHF 0.00
Prezzo di listino
Prezzo scontato
CHF 0.00
Prezzo unitario
/
per
Impossibile caricare la disponibilità di ritiro
Manufacturer :
Forthing
Article Nr. :
SKU:F1T1-C0102-1010010
