F1N1 - SIDE GUARD PANEL MODULE
F1N1 - SIDE GUARD PANEL MODULE
M6A15D65B17SR24 > Trim system > Side guard panel module
| Rep. | Designation | Reference | Qte/vehicule |
|---|---|---|---|
| 1 | Right C pillar upper guard assy | F1N1-M6-5402320S-Y3 | 1 |
| 2 | Right rear side wall cup holder mounting support assembly | F1N1-M6-5402980S | 1 |
| 3 | C-pillar air curtain plug cover (with word mark) | F1N1-M6-5402315S-Y1 | 2 |
| 4 | Lower right side cover | F1N1-M6-5402718S-Y1 | 1 |
| 5 | Square hole self-tapping nut buckle | F1N1-BL338B | 4 |
| 5 | Square hole self-tapping nut buckle | F1N1-BL338B | 2 |
| 6 | Left C pillar upper guard assy | F1N1-M6-5402310S-Y3 | 1 |
| 7 | Mounting bracket assembly for left rear side cup holder | F1N1-M6-5402970S | 1 |
| 8 | Rear side carpet trim assembly | F1N1-M6-5402810S-Y1 | 1 |
| 9 | Cold air duct side wall section assembly | F1N1-M6-5402811-Y1 | 1 |
| 10 | Right D-pillar upper guard assembly | F1N1-M6-5402420S-Y3 | 1 |
| 11 | Left D-pillar upper trim plate assembly | F1N1-M6-5402410S-Y3 | 1 |
| 12 | Cross recessed cup head tapping screw with large head | F1N1-Q2734816F38 | 2 |
| 12 | Cross recessed cup head tapping screw with large head | F1N1-Q2734816F38 | 2 |
| 13 | Lower left side cover | F1N1-M6-5402717S-Y1 | 1 |
| 14 | Cross recessed cup head tapping screw with large head | F1N1-Q2734825F38 | 2 |
| 15 | Left rear side enclosure lower guard plate assembly | F1N1-M6-5402610BS-Y3 | 1 |
| 16 | Cross recessed pan head screws | F1N1-Q2140616F38 | 4 |
| 16 | Cross recessed pan head screws | F1N1-Q2140616F38 | 10 |
| 17 | Left B-pillar lower guard plate assembly | F1N1-M6-5402270S-Y3 | 1 |
| 18 | upper panel assembly of left B pillar | F1N1-M6-5402210S-Y3 | 1 |
| 19 | Air curtain plug cover of left B pillar (with lettering) | F1N1-M6-5402227S-Y1 | 2 |
| 20 | Snap fastener | F1N1-BL611 | 2 |
| 21 | Lower panel assembly of left A pillar | F1N1-M6-5402150B-Y1 | 1 |
| 22 | Left A-pillar upper guard plate assembly | F1N1-M6-5402110S-Y3 | 1 |
| 23 | Right A-pillar lower guard plate assembly | F1N1-M6-5402160B-Y1 | 1 |
| 24 | Right A-pillar upper guard plate assembly | F1N1-M6-5402120S-Y3 | 1 |
| 25 | Inner rearview mirror shield | F1N1-M6-5402713S-Y1 | 1 |
| 26 | Inside mirror plug | F1N1-M6-5402715S-Y1 | 1 |
| 27 | Upper panel assembly of right B pillar | F1N1-M6-5402220S-Y3 | 1 |
| 28 | Right B-pillar lower guard plate assembly | F1N1-M6-5402280S-Y3 | 1 |
| 29 | Right rear side enclosure lower guard plate assembly | F1N1-M6-5402620B-Y3 | 1 |
| 30 | Rear side wall cup holder pad | F1N1-M6-5402632S-Y1 | 2 |
| 31 | Left rear side enclosure vehicle power supply plug cover | F1N1-M6-5402634B-Y1 | 1 |
| 32 | Car power supply cover | F1N1-M6-5402644B-Y1 | 1 |
| 33 | Left B-pillar lower guard plate blocking cover | F1N1-M6-5402351S-Y1 | 1 |
| 34 | Blocking cover of right B-pillar lower guard plate | F1N1-M6-5402361S-Y1 | 1 |
